Door Handling Reference

Door handing is determined by looking at the front of the door.

Bore Distance (A)

Most concealed door hinges for face frame cabinets require a 3 mm bore distance.

This distance is measured from the edge of the door to the edge of the 35 mm hinge cup hole.

Bore Offset (B & C)

The standard bore offset is 100 mm.

This distance is measured from the top or bottom edge of the door to the centre of the 35mm hinge cup hole.
